Raw material: Waste paper
Output(pcs/hr):500-700 900-1000
Certification: CE, ISO9001
Skype:lewis15863824208
MINI Egg Tray Machine Introduction:
MINI Pulp Moulding Machine which also named as Egg Tray Machine or Paper Machinery bring in advanced technology to develop and exploit our own FC brand products. It gets good comments from customer and gain social acceptance in society as a result of its excellent performance characteristic. The main part of our Egg Tray Machine use stainless steel material ,other auxiliary parts of Egg Tray Machine adopt domestic famous brand. We already develop automatic counting stacking and packing system etc.FC series Egg Tray machine features of high efficiency, low maintenance and energy saving .The pulp molding system can use all kinds of waste paper to produce high quality molded fiber products .With different moulds it can produce egg trays, vegetable trays, fruit trays, can trays, seedling tray, etc.
Principle of our Egg Tray Machine:
After take sanitary measures of the waste paper, put the waste paper into hydrapulper with water. After progress of batting pulp , grind pulp, size mixing, then send the pulp into molding machine by pump. The foaming mould continuously uniform rotation, the mould absorb the pulp by vacuum, the pulp which adsorb to the mould uniformly dehydrate by Filter and Dehydration hole, Guarantee product and the mould compatibility. when the foaming moulds matched with transfer moulds ,the automatic control system send compression air to control the forming molds, at the same time, transfer mold form a vacuum, the product is send to the transfer mould , then the transfer mold put the product on to the conveyer belt of drying line. The Egg Tray Machine line also equipped with automatic packing ,automatic stacking and counting system so the products can packing well.
Some advantages of Egg Tray Machine:
1.Cheap and very small.
2.High output.
3.Plug the power,You can use the machine.There is no need to install and debug.
4.Control by PLC.It is an automatic machine.
5.You don’t need to make Pulp Pool and Water pool.So it is very easily operate.
You can know more from the video link:
|
|
MINI Egg Tray Machine Images
|
